The FC01 series is a modular backwash controller specifically designed for automatic filtration systems. It features a built-in computer microchip and program editing. By utilizing a water pressure sensor (information input) and solenoid valves (information output), it integrates components such as backwash valves, filter units, and pressure-sustaining valves to form an automatic backwash filtration system. It can automatically and sequentially clean each filter unit online according to preset programs, achieving automatic removal of impurities from the entire system while maintaining uninterrupted filtered water supply, without affecting normal irrigation operations.

Equipped with a customized color LCD screen, the display interface is simple and user-friendly.

Dual language support (Chinese/English), with simple and easy-to-operate program settings.

Waterproof and moisture-proof design, suitable for various working environments.

10 output ports, capable of meeting the requirements for the number of filter units in most systems.

DC type comes with 4 size 1# batteries or a 5V DC power adapter, safe and reliable, with lightning strike protection.

Three backwash initiation modes can be set: timed start, differential pressure start, and manual start.

Flexible settings for backwash duration, backwash valve interval duration, and differential pressure detection response delay duration.

Automatically counts backwash cycles for convenient regular maintenance.

Automatically detects and displays the number of output backwash valve stations.

Displays a low-voltage alarm on the screen when battery voltage is insufficient.

One-key restore to factory default settings.

Built-in operation prompts, eliminating the need for complex manuals.

Display Screen: 3.5" Color LCD

Input Voltage: 5-6VDC

Output Voltage: 12VDC Pulse

Input Differential Pressure Range: 0-2.0 Bar

Output Stations: 10

Waterproof Rating: IP65

Operating Temperature: 0-60℃
